Latent semantic analysis

Latent semantic analysis (LSA) is a technique in natural language processing, in particular distributional semantics, of analyzing relationships between a set of documents and the terms they contain by producing a set of concepts related to the documents and terms. LSA assumes that words that are close in meaning will occur in similar pieces of text (the distributional hypothesis). A matrix containing word counts per document (rows represent unique words and columns represent each document) is constructed from a large piece of text and a mathematical technique called singular value decomposition (SVD) is used to reduce the number of rows while preserving the similarity structure among columns. Documents are then compared by cosine similarity between any two columns. Values close to 1 represent very similar documents while values close to 0 represent very dissimilar documents. An information retrieval technique using latent semantic structure was patented in 1988 by Scott Deerwester, Susan Dumais, George Furnas, Richard Harshman, Thomas Landauer, Karen Lochbaum and Lynn Streeter. In the context of its application to information retrieval, it is sometimes called latent semantic indexing (LSI). == Overview == === Occurrence matrix === LSA can use a document-term matrix which describes the occurrences of terms in documents; it is a sparse matrix whose rows correspond to terms and whose columns correspond to documents. A typical example of the weighting of the elements of the matrix is tf-idf (term frequency–inverse document frequency): the weight of an element of the matrix is proportional to the number of times the terms appear in each document, where rare terms are upweighted to reflect their relative importance. This matrix is also common to standard semantic models, though it is not necessarily explicitly expressed as a matrix, since the mathematical properties of matrices are not always used. === Rank lowering === After the construction of the occurrence matrix, LSA finds a low-rank approximation to the term-document matrix. There could be various reasons for these approximations: The original term-document matrix is presumed too large for the computing resources; in this case, the approximated low rank matrix is interpreted as an approximation (a "least and necessary evil"). The original term-document matrix is presumed noisy: for example, anecdotal instances of terms are to be eliminated. From this point of view, the approximated matrix is interpreted as a de-noisified matrix (a better matrix than the original). The original term-document matrix is presumed overly sparse relative to the "true" term-document matrix. That is, the original matrix lists only the words actually in each document, whereas we might be interested in all words related to each document—generally a much larger set due to synonymy. The consequence of the rank lowering is that some dimensions are combined and depend on more than one term: {(car), (truck), (flower)} → {(1.3452 car + 0.2828 truck), (flower)} This mitigates the problem of identifying synonymy, as the rank lowering is expected to merge the dimensions associated with terms that have similar meanings. It also partially mitigates the problem with polysemy, since components of polysemous words that point in the "right" direction are added to the components of words that share a similar meaning. Conversely, components that point in other directions tend to either simply cancel out, or, at worst, to be smaller than components in the directions corresponding to the intended sense. === Derivation === Let X {\displaystyle X} be a matrix where element ( i , j ) {\displaystyle (i,j)} describes the occurrence of term i {\displaystyle i} in document j {\displaystyle j} (this can be, for example, the frequency). X {\displaystyle X} will look like this: d j ↓ t i T → [ x 1 , 1 … x 1 , j … x 1 , n ⋮ ⋱ ⋮ ⋱ ⋮ x i , 1 … x i , j … x i , n ⋮ ⋱ ⋮ ⋱ ⋮ x m , 1 … x m , j … x m , n ] {\displaystyle {\begin{matrix}&{\textbf {d}}_{j}\\&\downarrow \\{\textbf {t}}_{i}^{T}\rightarrow &{\begin{bmatrix}x_{1,1}&\dots &x_{1,j}&\dots &x_{1,n}\\\vdots &\ddots &\vdots &\ddots &\vdots \\x_{i,1}&\dots &x_{i,j}&\dots &x_{i,n}\\\vdots &\ddots &\vdots &\ddots &\vdots \\x_{m,1}&\dots &x_{m,j}&\dots &x_{m,n}\\\end{bmatrix}}\end{matrix}}} Now a row in this matrix will be a vector corresponding to a term, giving its relation to each document: t i T = [ x i , 1 … x i , j … x i , n ] {\displaystyle {\textbf {t}}_{i}^{T}={\begin{bmatrix}x_{i,1}&\dots &x_{i,j}&\dots &x_{i,n}\end{bmatrix}}} Likewise, a column in this matrix will be a vector corresponding to a document, giving its relation to each term: d j = [ x 1 , j ⋮ x i , j ⋮ x m , j ] {\displaystyle {\textbf {d}}_{j}={\begin{bmatrix}x_{1,j}\\\vdots \\x_{i,j}\\\vdots \\x_{m,j}\\\end{bmatrix}}} Now the dot product t i T t p {\displaystyle {\textbf {t}}_{i}^{T}{\textbf {t}}_{p}} between two term vectors gives the correlation between the terms over the set of documents. The matrix product X X T {\displaystyle XX^{T}} contains all these dot products. Element ( i , p ) {\displaystyle (i,p)} (which is equal to element ( p , i ) {\displaystyle (p,i)} ) contains the dot product t i T t p {\displaystyle {\textbf {t}}_{i}^{T}{\textbf {t}}_{p}} ( = t p T t i {\displaystyle ={\textbf {t}}_{p}^{T}{\textbf {t}}_{i}} ). Likewise, the matrix X T X {\displaystyle X^{T}X} contains the dot products between all the document vectors, giving their correlation over the terms: d j T d q = d q T d j {\displaystyle {\textbf {d}}_{j}^{T}{\textbf {d}}_{q}={\textbf {d}}_{q}^{T}{\textbf {d}}_{j}} . Now, from the theory of linear algebra, there exists a decomposition of X {\displaystyle X} such that U {\displaystyle U} and V {\displaystyle V} are orthogonal matrices and Σ {\displaystyle \Sigma } is a diagonal matrix. This is called a singular value decomposition (SVD): X = U Σ V T {\displaystyle {\begin{matrix}X=U\Sigma V^{T}\end{matrix}}} The matrix products giving us the term and document correlations then become X X T = ( U Σ V T ) ( U Σ V T ) T = ( U Σ V T ) ( V T T Σ T U T ) = U Σ V T V Σ T U T = U Σ Σ T U T X T X = ( U Σ V T ) T ( U Σ V T ) = ( V T T Σ T U T ) ( U Σ V T ) = V Σ T U T U Σ V T = V Σ T Σ V T {\displaystyle {\begin{matrix}XX^{T}&=&(U\Sigma V^{T})(U\Sigma V^{T})^{T}=(U\Sigma V^{T})(V^{T^{T}}\Sigma ^{T}U^{T})=U\Sigma V^{T}V\Sigma ^{T}U^{T}=U\Sigma \Sigma ^{T}U^{T}\\X^{T}X&=&(U\Sigma V^{T})^{T}(U\Sigma V^{T})=(V^{T^{T}}\Sigma ^{T}U^{T})(U\Sigma V^{T})=V\Sigma ^{T}U^{T}U\Sigma V^{T}=V\Sigma ^{T}\Sigma V^{T}\end{matrix}}} Since Σ Σ T {\displaystyle \Sigma \Sigma ^{T}} and Σ T Σ {\displaystyle \Sigma ^{T}\Sigma } are diagonal we see that U {\displaystyle U} must contain the eigenvectors of X X T {\displaystyle XX^{T}} , while V {\displaystyle V} must be the eigenvectors of X T X {\displaystyle X^{T}X} . Both products have the same non-zero eigenvalues, given by the non-zero entries of Σ Σ T {\displaystyle \Sigma \Sigma ^{T}} , or equally, by the non-zero entries of Σ T Σ {\displaystyle \Sigma ^{T}\Sigma } . Now the decomposition looks like this: X U Σ V T ( d j ) ( d ^ j ) ↓ ↓ ( t i T ) → [ x 1 , 1 … x 1 , j … x 1 , n ⋮ ⋱ ⋮ ⋱ ⋮ x i , 1 … x i , j … x i , n ⋮ ⋱ ⋮ ⋱ ⋮ x m , 1 … x m , j … x m , n ] = ( t ^ i T ) → [ [ u 1 ] … [ u l ] ] ⋅ [ σ 1 … 0 ⋮ ⋱ ⋮ 0 … σ l ] ⋅ [ [ v 1 ] ⋮ [ v l ] ] {\displaystyle {\begin{matrix}&X&&&U&&\Sigma &&V^{T}\\&({\textbf {d}}_{j})&&&&&&&({\hat {\textbf {d}}}_{j})\\&\downarrow &&&&&&&\downarrow \\({\textbf {t}}_{i}^{T})\rightarrow &{\begin{bmatrix}x_{1,1}&\dots &x_{1,j}&\dots &x_{1,n}\\\vdots &\ddots &\vdots &\ddots &\vdots \\x_{i,1}&\dots &x_{i,j}&\dots &x_{i,n}\\\vdots &\ddots &\vdots &\ddots &\vdots \\x_{m,1}&\dots &x_{m,j}&\dots &x_{m,n}\\\end{bmatrix}}&=&({\hat {\textbf {t}}}_{i}^{T})\rightarrow &{\begin{bmatrix}{\begin{bmatrix}\,\\\,\\{\textbf {u}}_{1}\\\,\\\,\end{bmatrix}}\dots {\begin{bmatrix}\,\\\,\\{\textbf {u}}_{l}\\\,\\\,\end{bmatrix}}\end{bmatrix}}&\cdot &{\begin{bmatrix}\sigma _{1}&\dots &0\\\vdots &\ddots &\vdots \\0&\dots &\sigma _{l}\\\end{bmatrix}}&\cdot &{\begin{bmatrix}{\begin{bmatrix}&&{\textbf {v}}_{1}&&\end{bmatrix}}\\\vdots \\{\begin{bmatrix}&&{\textbf {v}}_{l}&&\end{bmatrix}}\end{bmatrix}}\end{matrix}}} The values σ 1 , … , σ l {\displaystyle \sigma _{1},\dots ,\sigma _{l}} are called the singular values, and u 1 , … , u l {\displaystyle u_{1},\dots ,u_{l}} and v 1 , … , v l {\displaystyle v_{1},\dots ,v_{l}} the left and right singular vectors. Notice the only part of U {\displaystyle U} that contributes to t i {\displaystyle {\textbf {t}}_{i}} is the i 'th {\displaystyle i{\textrm {'th}}} row. Let this row vector be called t ^ i T {\displaystyle {\hat {\textrm {t}}}_{i}^{T}} . Likewise, the only part of V T {\displaystyle V^{T}} that contributes to d j {\displaystyle {\textbf {d}}_{j}} is the j 'th {\displaystyle j{\textrm {'th}}} column, d ^ j {\displaystyle {\hat {\textrm {d}}}_{j}} . These are not the eigenvectors, but depend on all the eigenvectors. I

RemObjects Software

RemObjects Software is an American software company founded in 2002 by Alessandro Federici and Marc Hoffman. It develops and offers tools and libraries for software developers on a variety of development platforms, including Embarcadero Delphi, Microsoft .NET, Mono, and Apple's Xcode. == History == RemObjects Software was founded in the summer of 2002. Its first product was RemObjects SDK 1.0 for Delphi, the company's remoting solution which is now in its 6th version. In late 2003 RemObjects expanded its product portfolio to add Data Abstract for Delphi, a multi-tier database framework built on top of the SDK. In 2004, Carlo Kok, who would eventually become Chief Compiler Architect for Oxygene, joined the company, adding the open source Pascal Script library for Delphi to the company's portfolio. Initial development began on Oxygene (which was then named Chrome) based on Carlo's experience from writing the widely used Pascal Script scripting engine. Towards the end of 2004, RemObjects SDK for .NET was released, expanding the remoting framework to its second platform. Chrome 1.0 was released in mid-2005, providing support for .NET 1.1 and .NET 2.0, which was still in beta at the time - making Chrome the first shipping language for .NET that supported features such as generics. It was followed by Chrome 1.5 when .NET 2.0 shipped in November of the same year. 2005 also saw the expansion of Data Abstract to .NET as a second platform. Data Abstract for .NET was the first RemObjects product (besides Oxygene itself) to be written in Oxygene. Hydra 3.0, was released for .NET in December 2006, bringing a paradigm shift to the product, away from a regular plugin framework, and focusing on interoperability between plugins and host applications written in either .NET or Delphi/Win32, essentially enabling the use of both managed and unmanaged code in the same project. In Summer 2007, RemObjects released Chrome 'Joyride' which added official support for .NET 3.0 and 3.5. Chrome once again was the first language to ship release level support for new .NET framework features supported by that runtime - most importantly Sequences and Queries (aka LINQ). Development continued and in May 2008 Oxygene 3.0 was released, dropping the "Chrome" moniker. Oxygene once again brought major language enhancements, including extensive support for concurrency and parallel programming as part of the language syntax. In October 2008, RemObjects Software and Embarcadero Technologies announced plans to collaborate and ship future versions of Oxygene under the Delphi Prism moniker, later changed to Embarcadero Prism. The first of these releases of Prism became available in December 2008. Over the course of 2009, RemObjects software completed the expansion of its Data Abstract and RemObjects SDK product combo to a third development platform - Xcode and Cocoa, for both Mac OS X and iPhone SDK client development. RemObjects SDK for OS X shipped in the spring of 2009, followed by Data Abstract for OS X in the fall. In 2011, Oxygene was expanded to add support for the Java platform, in addition to NET. In 2014, RemObjects introduced a C# compiler which runs as a Visual Studio 2013 plugin, that can output code for iOS, MacOS (Cocoa) and Android, in addition to .NET compatible code. In addition, an IDE called Fire was introduced for macOS which works with their C# and Oxygene compilers. Together, the compiler supporting both Oxygene and C# was rebranded as the Elements Compiler, with CE# having the Code name "Hydrogene". In February 2015, RemObjects introduced a beta version of a Swift compiler called Silver as part of its Elements effort. Silver, too, could create code that will execute on Android, the JVM, .NET platform and also create native Cocoa code. Silver added new features to the Swift language, such as exceptions and has a few differences and limitations compared to Apple's Swift. In February 2020, support for the Go programming language was introduced with RemObjects Gold, including the ability to compile Go language code for all Elements platforms, and a port of the extensive Go Base Library available to all Elements languages. In 2021, Mercury was added to the Elements compiler as the sixth language, providing a future for the Visual Basic .NET language recently deprecated by Microsoft. Mercury supports building and maintaining existing VB.NET projects, as well as using the language for new projects both on .NET and the other platforms. == Commercial products == Elements is a development toolchain that targets .NET runtime, Java/Android virtual machines, the Apple ecosystem (macOS, iOS, tvOS), WebAssembly and native and Windows/Linux/Android NDK processor-native machine code in conjunction with a runtime library that does automatic garbage collection on non-ARC environments and ARC on ARC-based environments, such as iOS and MacOS. Because Java, C#, Swift, and Oxygene all can import each other's APIs, Elements effectively functions as Java bonded together with C# bonded together with Swift bonded together with Oxygene as a confederation of languages cooperating together quite intimately. Oxygene, a unique programming language based on Object Pascal, which can import Java, C#, and Swift APIs from the runtime of the target operating system; RemObjects C#, an implementation of C# programming language, which can import Java, Swift, and Oxygene APIs from the runtime of the target operating system and which is intended as a competitor of Xamarin, but Hydrogene's C# targets JVM bytecode instead of Xamarin's C# compiling to only Common Language Infrastructure byte code and needing the accompanying Mono Common Language Runtime to be present in such JVM-centric environments as Android; Silver, a free implementation of the Swift programming language, which can import Java, C#, and Oxygene APIs from the runtime of the target operating system; Iodine, an implementation of the Java programming language. Gold, an implementation of the Go programming language. Mercury, an implementation of the Visual Basic .NET programming language. Fire an integrated development environment for macOS. Water an integrated development environment for Windows. Data Abstract Remoting SDK, a.k.a. RemObjects SDK Hydra Oxfuscator Oxidizer, an automatic translator from Java, C#, Objective-C, and Delphi to Oxygene, from Java, Objective-C, and C# to Swift, and from Java and Objective-C to C#. == Open source projects == Train is an open-source JavaScript-based tool for building and running build scripts and automation. Internet Pack for .NET is a free, open source library for building network clients and servers using TCP and higher level protocols such as HTTP or FTP, using the .NET or Mono platforms. It includes a range of ready to use protocol implementations, as well as base classes that allow the creation of custom implementations. RemObjects Script for .NET is a fully managed ECMAScript implementation for .NET and Mono. Pascal Script for Delphi is a widely used implementation of Pascal as scripting language. == Involvement of other projects == The Oxygene Compiler Oxygene is a language based on Object Pascal and designed to efficiently target the Microsoft .NET and Mono managed runtimes; it expands Object Pascal with a range of additional language features, such as Aspect Oriented Programming, Class Contracts and support for Parallelism. It integrates with the Microsoft Visual Studio and MonoDevelop IDEs.

Open Data-Link Interface

The Open Data-Link Interface (ODI) is an application programming interface (API) for network interface controllers (NICs) developed by Apple and Novell. The API serves the same function as Microsoft and 3COM's Network Driver Interface Specification (NDIS). Originally, ODI was written for NetWare and Macintosh environments. Like NDIS, ODI provides rules that establish a vendor-neutral interface between the protocol stack and the adapter driver. It resides in Layer 2, the Data Link layer, of the OSI model. This interface also enables one or more network drivers to support one or more protocol stacks.

Plaintext

In cryptography, plaintext usually means unencrypted information pending input into cryptographic algorithms, usually encryption algorithms. This usually refers to data that is transmitted or stored unencrypted. == Overview == With the advent of computing, the term plaintext expanded beyond human-readable documents to mean any data, including binary files, in a form that can be viewed or used without requiring a key or other decryption device. Information—a message, document, file, etc.—if to be communicated or stored in an unencrypted form is referred to as plaintext. Plaintext is used as input to an encryption algorithm; the output is usually termed ciphertext, particularly when the algorithm is a cipher. Codetext is less often used, and almost always only when the algorithm involved is actually a code. Some systems use multiple layers of encryption, with the output of one encryption algorithm becoming "plaintext" input for the next. == Secure handling == Insecure handling of plaintext can introduce weaknesses into a cryptosystem by letting an attacker bypass the cryptography altogether. Plaintext is vulnerable in use and in storage, whether in electronic or paper format. Physical security means the securing of information and its storage media from physical, attack—for instance by someone entering a building to access papers, storage media, or computers. Discarded material, if not disposed of securely, may be a security risk. Even shredded documents and erased magnetic media might be reconstructed with sufficient effort. If plaintext is stored in a computer file, the storage media, the computer and its components, and all backups must be secure. Sensitive data is sometimes processed on computers whose mass storage is removable, in which case physical security of the removed disk is vital. In the case of securing a computer, useful (as opposed to handwaving) security must be physical (e.g., against burglary, brazen removal under cover of supposed repair, installation of covert monitoring devices, etc.), as well as virtual (e.g., operating system modification, illicit network access, Trojan programs). Wide availability of keydrives, which can plug into most modern computers and store large quantities of data, poses another severe security headache. A spy (perhaps posing as a cleaning person) could easily conceal one, and even swallow it if necessary. Discarded computers, disk drives and media are also a potential source of plaintexts. Most operating systems do not actually erase anything— they simply mark the disk space occupied by a deleted file as 'available for use', and remove its entry from the file system directory. The information in a file deleted in this way remains fully present until overwritten at some later time when the operating system reuses the disk space. With even low-end computers commonly sold with many gigabytes of disk space and rising monthly, this 'later time' may be months later, or never. Even overwriting the portion of a disk surface occupied by a deleted file is insufficient in many cases. Peter Gutmann of the University of Auckland wrote a celebrated 1996 paper on the recovery of overwritten information from magnetic disks; areal storage densities have gotten much higher since then, so this sort of recovery is likely to be more difficult than it was when Gutmann wrote. Modern hard drives automatically remap failing sectors, moving data to good sectors. This process makes information on those failing, excluded sectors invisible to the file system and normal applications. Special software, however, can still extract information from them. Some government agencies (e.g., US NSA) require that personnel physically pulverize discarded disk drives and, in some cases, treat them with chemical corrosives. This practice is not widespread outside government, however. Garfinkel and Shelat (2003) analyzed 158 second-hand hard drives they acquired at garage sales and the like, and found that less than 10% had been sufficiently sanitized. The others contained a wide variety of readable personal and confidential information. See data remanence. Physical loss is a serious problem. The US State Department, Department of Defense, and the British Secret Service have all had laptops with secret information, including in plaintext, lost or stolen. Appropriate disk encryption techniques can safeguard data on misappropriated computers or media. On occasion, even when data on host systems is encrypted, media that personnel use to transfer data between systems is plaintext because of poorly designed data policy. For example, in October 2007, HM Revenue and Customs lost CDs that contained the unencrypted records of 25 million child benefit recipients in the United Kingdom. Modern cryptographic systems resist known plaintext or even chosen plaintext attacks, and so may not be entirely compromised when plaintext is lost or stolen. Older systems resisted the effects of plaintext data loss on security with less effective techniques—such as padding and Russian copulation to obscure information in plaintext that could be easily guessed.

Data thinking

Data Thinking is a framework that integrates data science with the design process. It combines computational thinking, statistical thinking, and domain-specific knowledge to guide the development of data-driven solutions in product development. The framework is used to explore, design, develop, and validate solutions, with a focus on user experience and data analytics, including data collection and interpretation The framework aims to apply data literacy and inform decision-making through data-driven insights. == Major components == According to "Computational thinking in the era of data science": Data thinking involves understanding that solutions require both data-driven and domain-knowledge-driven rules. Data thinking evaluates whether data accurately represents real-life scenarios and improves data collection where necessary. The framework highlights the importance of preserving domain-specific meaning during data analysis. Data thinking incorporates statistical and logical analysis to identify patterns and irregularities. Data thinking involves testing solutions in real-life contexts and iteratively improving models based on new data. The process requires evaluating problems from multiple abstraction levels and understanding the potential for biases in generalizations. == Major phases == === Strategic context and risk analysis === Analyzing the broader digital strategy and assessing risks and opportunities is a common step before beginning a project. Techniques like coolhunting, trend analysis, and scenario planning can be used to assist with this. === Ideation and exploration === In this phase, focus areas are identified, and use cases are developed by integrating organizational goals, user needs, and data requirements. Design thinking methods, such as personas and customer journey mapping, are applied. === Prototyping === A proof of concept is created to test feasibility and refine solutions through iterative evaluation to optimize for effective performance. === Implementation and monitoring === Solutions are tested and monitored for performance and continual improvement. == Implementing Data Thinking == The following resources explain more about data thinking and its applications: "Data Thinking: Framework for data-based solutions" by StackFuel "What is Data Thinking? A modern approach to designing a data strategy" by Mantel Group "Data Science Thinking" by SpringerLink These sources provide detailed insights into the methodology, phases, and benefits of adopting Data Thinking in organizational processes.

Image stitching

Image stitching or photo stitching is the process of combining multiple photographic images with overlapping fields of view to produce a segmented panorama or high-resolution image. Commonly performed through the use of computer software, most approaches to image stitching require nearly exact overlaps between images and identical exposures to produce seamless results, although some stitching algorithms actually benefit from differently exposed images by doing high-dynamic-range imaging in regions of overlap. Some digital cameras can stitch their photos internally. == Applications == Image stitching is widely used in modern applications, such as the following: Document mosaicing Image stabilization feature in camcorders that use frame-rate image alignment High-resolution image mosaics in digital maps and satellite imagery Medical imaging Multiple-image super-resolution imaging Video stitching Object insertion == Process == The image stitching process can be divided into three main components: image registration, calibration, and blending. === Image stitching algorithms === In order to estimate image alignment, algorithms are needed to determine the appropriate mathematical model relating pixel coordinates in one image to pixel coordinates in another. Algorithms that combine direct pixel-to-pixel comparisons with gradient descent (and other optimization techniques) can be used to estimate these parameters. Distinctive features can be found in each image and then efficiently matched to rapidly establish correspondences between pairs of images. When multiple images exist in a panorama, techniques have been developed to compute a globally consistent set of alignments and to efficiently discover which images overlap one another. A final compositing surface onto which to warp or projectively transform and place all of the aligned images is needed, as are algorithms to seamlessly blend the overlapping images, even in the presence of parallax, lens distortion, scene motion, and exposure differences. === Image stitching issues === Since the illumination in two views cannot be guaranteed to be identical, stitching two images could create a visible seam. Other reasons for seams could be the background changing between two images for the same continuous foreground. Other major issues to deal with are the presence of parallax, lens distortion, scene motion, and exposure differences. In a non-ideal real-life case, the intensity varies across the whole scene, and so does the contrast and intensity across frames. Additionally, the aspect ratio of a panorama image needs to be taken into account to create a visually pleasing composite. For panoramic stitching, the ideal set of images will have a reasonable amount of overlap (at least 15–30%) to overcome lens distortion and have enough detectable features. The set of images will have consistent exposure between frames to minimize the probability of seams occurring. === Keypoint detection === Feature detection is necessary to automatically find correspondences between images. Robust correspondences are required in order to estimate the necessary transformation to align an image with the image it is being composited on. Corners, blobs, Harris corners, and differences of Gaussians of Harris corners are good features since they are repeatable and distinct. One of the first operators for interest point detection was developed by Hans Moravec in 1977 for his research involving the automatic navigation of a robot through a clustered environment. Moravec also defined the concept of "points of interest" in an image and concluded these interest points could be used to find matching regions in different images. The Moravec operator is considered to be a corner detector because it defines interest points as points where there are large intensity variations in all directions. This often is the case at corners. However, Moravec was not specifically interested in finding corners, just distinct regions in an image that could be used to register consecutive image frames. Harris and Stephens improved upon Moravec's corner detector by considering the differential of the corner score with respect to direction directly. They needed it as a processing step to build interpretations of a robot's environment based on image sequences. Like Moravec, they needed a method to match corresponding points in consecutive image frames, but were interested in tracking both corners and edges between frames. SIFT and SURF are recent key-point or interest point detector algorithms but a point to note is that SURF is patented and its commercial usage restricted. Once a feature has been detected, a descriptor method like SIFT descriptor can be applied to later match them. === Registration === Image registration involves matching features in a set of images or using direct alignment methods to search for image alignments that minimize the sum of absolute differences between overlapping pixels. When using direct alignment methods one might first calibrate one's images to get better results. Additionally, users may input a rough model of the panorama to help the feature matching stage, so that e.g. only neighboring images are searched for matching features. Since there are smaller group of features for matching, the result of the search is more accurate and execution of the comparison is faster. To estimate a robust model from the data, a common method used is known as RANSAC. The name RANSAC is an abbreviation for "RANdom SAmple Consensus". It is an iterative method for robust parameter estimation to fit mathematical models from sets of observed data points which may contain outliers. The algorithm is non-deterministic in the sense that it produces a reasonable result only with a certain probability, with this probability increasing as more iterations are performed. It being a probabilistic method means that different results will be obtained for every time the algorithm is run. The RANSAC algorithm has found many applications in computer vision, including the simultaneous solving of the correspondence problem and the estimation of the fundamental matrix related to a pair of stereo cameras. The basic assumption of the method is that the data consists of "inliers", i.e., data whose distribution can be explained by some mathematical model, and "outliers" which are data that do not fit the model. Outliers are considered points which come from noise, erroneous measurements, or simply incorrect data. For the problem of homography estimation, RANSAC works by trying to fit several models using some of the point pairs and then checking if the models were able to relate most of the points. The best model – the homography, which produces the highest number of correct matches – is then chosen as the answer for the problem; thus, if the ratio of number of outliers to data points is very low, the RANSAC outputs a decent model fitting the data. === Calibration === Image calibration aims to minimize differences between an ideal lens models and the camera-lens combination that was used, optical defects such as distortions, exposure differences between images, vignetting, camera response and chromatic aberrations. If feature detection methods were used to register images and absolute positions of the features were recorded and saved, stitching software may use the data for geometric optimization of the images in addition to placing the images on the panosphere. Panotools and its various derivative programs use this method. ==== Alignment ==== Alignment may be necessary to transform an image to match the view point of the image it is being composited with. Alignment, in simple terms, is a change in the coordinates system so that it adopts a new coordinate system which outputs image matching the required viewpoint. The types of transformations an image may go through are pure translation, pure rotation, a similarity transform which includes translation, rotation and scaling of the image which needs to be transformed, Affine or projective transform. Projective transformation is the farthest an image can transform (in the set of two dimensional planar transformations), where only visible features that are preserved in the transformed image are straight lines whereas parallelism is maintained in an affine transform. Projective transformation can be mathematically described as x ′ = H ⋅ x , {\displaystyle x'=H\cdot x,} where x {\displaystyle x} is points in the old coordinate system, x ′ {\displaystyle x'} is the corresponding points in the transformed image and H {\displaystyle H} is the homography matrix. Expressing the points x {\displaystyle x} and x ′ {\displaystyle x'} using the camera intrinsics ( K {\displaystyle K} and K ′ {\displaystyle K'} ) and its rotation and translation [ R t ] {\displaystyle [R\,t]} to the real-world coordinates X {\displaystyle X} and < m a t h > x {\displaystyle $x\}\; and\; x\; \prime \; \{\backslash displaystyle\; x\text{'}\}\; \text{'}$, we get Using the abo

Multistage interconnection networks

Multistage interconnection networks (MINs) are a class of high-speed computer networks usually composed of processing elements (PEs) on one end of the network and memory elements (MEs) on the other end, connected by switching elements (SEs). The switching elements themselves are usually connected to each other in stages, hence the name. MINs are typically used in high-performance or parallel computing as a low-latency interconnection (as opposed to traditional packet switching networks), though they could be implemented on top of a packet switching network. Though the network is typically used for routing purposes, it could also be used as a co-processor to the actual processors for such uses as sorting; cyclic shifting, as in a perfect shuffle network; and bitonic sorting. == Background == Interconnection network are used to connect nodes, where nodes can be a single processor or group of processors, to other nodes. Interconnection networks can be categorized on the basis of their topology. Topology is the pattern in which one node is connected to other nodes. There are two main types of topology: static and dynamic. Static interconnect networks are hard-wired and cannot change their configurations. A regular static interconnect is mainly used in small networks made up of loosely couple nodes. The regular structure signifies that the nodes are arranged in specific shape and the shape is maintained throughout the networks. Some examples of static regular interconnections are: Completely connected network In a mesh network, multiple nodes are connected with each other. Each node in the network is connected to every other node in the network. This arrangement allows proper communication of the data between the nodes. But, there are a lot of communication overheads due to the increased number of node connections. Shared busThis network topology involves connection of the nodes with each other over a bus. Every node communicates with every other node using the bus. The bus utility ensures that no data is sent to the wrong node. But, the bus traffic is an important parameter which can affect the system. RingThis is one of the simplest ways of connecting nodes with each other. The nodes are connected with each other to form a ring. For a node to communicate with some other node, it has to send the messages to its neighbor. Therefore, the data message passes through a series of other nodes before reaching the destination. This involves increased latency in the system. TreeThis topology involves connection of the nodes to form a tree. The nodes are connected to form clusters and the clusters are in-turn connected to form the tree. This methodology causes increased complexity in the network. Hypercube This topology consists of connections of the nodes to form cubes. The nodes are also connected to the nodes on the other cubes. ButterflyThis is one of the most complex connections of the nodes. As the figure suggests, there are nodes which are connected and arranged in terms of their ranks. They are arranged in the form of a matrix. In dynamic interconnect networks, the nodes are interconnected via an array of simple switching elements. This interconnection can then be changed by use of routing algorithms, such that the path from one node to other nodes can be varied. Dynamic interconnections can be classified as: Single stage Interconnect Network Multistage interconnect Network Crossbar switch connections == Crossbar Switch Connections == In crossbar switch, there is a dedicated path from one processor to other processors. Thus, if there are n inputs and m outputs, we will need nm switches to realize a crossbar. As the number of outputs increases, the number of switches increases by factor of n. For large network this will be a problem. An alternative to this scheme is staged switching. == Single Stage Interconnect Network == In a single stage interconnect network, the input nodes are connected to output via a single stage of switches. The figure shows 88 single stage switch using shuffle exchange. As one can see, from a single shuffle, not all input can reach all output. Multiple shuffles are required for all inputs to be connected to all the outputs. == Multistage Interconnect Network == A multistage interconnect network is formed by cascading multiple single stage switches. The switches can then use their own routing algorithm, or be controlled by a centralized router, to form a completely interconnected network. Multistage Interconnect Network can be classified into three types: Non-blocking: A non-blocking network can connect any idle input to any idle output, regardless of the connections already established across the network. Crossbar is an example of this type of network. Rearrangeable non-blocking: This type of network can establish all possible connections between inputs and outputs by rearranging its existing connections. Blocking: This type of network cannot realize all possible connections between inputs and outputs. This is because a connection between one free input to another free output is blocked by an existing connection in the network. The number of switching elements required to realize a non-blocking network in highest, followed by rearrangeable non-blocking. Blocking network uses least switching elements. == Examples == Multiple types of multistage interconnection networks exist. === Omega network === An Omega network consists of multiple stages of 22 switching elements. Each input has a dedicated connection to an output. An NN omega network has log2(N) stages and N/2 switching elements in each stage for a perfect shuffle between stages. Thus the network has complexity of 0(N log(N)). Each switching element can employ its own switching algorithm. Consider an 88 omega network. There are 8! = 40320 1-to-1 mappings from input to output. There are 12 switching element for a total permutation of 2^12 = 4096. Thus, it is a blocking network. === Clos network === A Clos network uses 3 stages to switch from N inputs to N outputs. In the first stage, there are r= N/n crossbar switches and each switch is of size nm. In the second stage there are m switches of size rr and finally the last stage is a mirror of the first stage with r switches of size mn. A clos network will be completely non-blocking if m >= 2n-1. The number of connections, though more than omega network is much less than that of a crossbar network. === Beneš network === A Beneš network is a rearrangeably non-blocking network derived from the clos network by initializing n = m = 2. There are (2log2(N) - 1) stages, with each stage containing N/2 22 crossbar switches. An 88 Beneš network has 5 stages of switching elements, and each stage has 4 switching elements. The center three stages has two 44 benes network. The 44 Beneš network, can connect any input to any output recursively.
